Outswing Phantom Inserts

AWS 114
The Schuco AWS 114 is an innovative window system that can achieve massive sizes by utilizing state-of-the-art concealed motors and automation. Its all-glass facade with stepped glazing integrates into the FWS 50.SI curtainwall to create a seamless exterior aesthetic.
The window is available in the top-hung awning and parallel arm typologies. Manual versions are available as well.
PROFILE
CONFIGURATION
TOP HUNG
PARALLEL
LIMITATIONS

MINIMUM SIZES

MINIMUM SIZES @300Pa | 6.27 psf
MAXIMUM SIZES
MAXIMUM WEIGHT
OPERABLE WINDOW LIMITATIONS (CW DLO)
550 mm x 500 mm

1550 mm x 3650 mm; 2750 mm x 2550 mm

160 kg
PERFORMANCE TEST
AIR INFILTRATION @300Pa | 6.27 psf
WATER PENETRATION
THERMAL - DOUBLE GLASS
THERMAL - TRIPLE GLASS
OPERABLE WINDOW PERFORMANCE

A3 | 0.01 L/s/m2 | <0.01 cfm/ft2

720 Pa | 15.04 psf

1.82-1.99 W/m2K | 0.32-0.35 Btu

1.31-1.59 W/m2K | 0.23-0.28 Btu

HANDLES
Black
Silver
Stainless Steel

DETAILS

Elegant and unique, this aluminum door adds vertical drama to any entrance. A perfectly flat surface with discreetly concealed handle and elongated window.
AWS 114

GLAZING & FINISHING OPTIONS

Elegant and unique, this aluminum door adds vertical drama to any entrance.
GLAZING & FINISHING
