Fixed & Inswing Windows

AWS 75.SI+

The Schüco AWS 75.SI+ (Super Insulation) window system sets a new standard for aluminum windows without compromising comfort, design, or functionality. With a basic depth of 75mm (2 15/16”), the narrow profile face widths ensure maximum transparency,

which guarantees that your living and workspace is bright and flooded with light. Operable units are available as tilt & turn, hopper and terrace door.

PROFILE

Standard

Extended

CONFIGURATION

OPERABLE WINDOWS

Tilt & Turn

Side Hung

Bottom Hung

Double Tilt & Turn

Double Side Hung

CONFIGURATION

TERRACE DOORS

Tilt & Turn

Side Hung

Double Tilt & Turn

Double Side Hung

LIMITATIONS

MINIMUM SIZES

MINIMUM SIZES @300Pa | 6.27 psf

MAXIMUM SIZES

MAXIMUM WEIGHT

OPERABLE WINDOWS

470 mm x 540 mm

1000 mm x 2500 mm | 1700 mm x 2100 mm

160 kg

PERFORMANCE TEST

AIR INFILTRATION @300Pa | 6.27 psf

WATER PENETRATION

THERMAL - DOUBLE GLASS

THERMAL - TRIPLE GLASS

FIXED WINDOW

<0.3 L/s/m2 | <0.01 cfm/ft2

B7 | 720 Pa | 15.04 psf

11.36-1.59 W/m2K | 0.24-0.28 Btu

0.91-1.19 W/m2K | 0.16-0.21 Btu

OPERABLE WINDOWS

A3 0.3 L/s/m2 | <0.05 cfm/ft2

B7 | 720 Pa | 15.04 psf

1.48-1.65 W/m2K | 0.26-0.29 Btu

1.08-1.31 W/m2K | 0.19-0.23 Btu

HANDLES

Black

Silver

Stainless Steel

DETAILS

Elegant and unique, this aluminum door adds vertical drama to any entrance. A perfectly flat surface with discreetly concealed handle and elongated window.

GLAZING & FINISHING OPTIONS

Elegant and unique, this aluminum door adds vertical drama to any entrance.

GLAZING & FINISHING
