The V-95 is a versatile, high insulation casement and awning window system. With a basic depth of 95mm (3 ¾"), it features triple seal technology and additional foam insulation for enhanced performance.
The V-95's elegant design, functionality and size capabilities make it a standout option for any project.
PROFILE
CONFIGURATION
Side Hung
Top Hung
LIMITATIONS
MINIMUM SIZES
MINIMUM SIZES @300Pa | 6.27 psf
MAXIMUM SIZES
MAXIMUM WEIGHT
AWNING WINDOW
470 mm x 457 mm
1524 mm x 2438 mm
160 kg
LIMITATIONS
MINIMUM SIZES
MINIMUM SIZES @300Pa | 6.27 psf
MAXIMUM SIZES
MAXIMUM WEIGHT
CASEMENT WINDOW
559 mm x 559 mm
1067 mm x 2438 mm
100 kg
PERFORMANCE TEST
AIR INFILTRATION @300Pa | 6.27 psf
WATER PENETRATION
THERMAL - DOUBLE GLASS
THERMAL - TRIPLE GLASS
WINDOW PERFORMANCE
A3
720 Pa | 15.04 psf
1.77 - 1.94 W/m2K | 0.31 - 0.34 Btu
1.38 - 1.60 W/m2K | 0.24 - 0.28 Btu
HANDLES
Black
Black Roto
Silver
Silver Roto
DETAILS
Elegant and unique, this aluminum door adds vertical drama to any entrance. A perfectly flat surface with discreetly concealed handle and elongated window.
