LIFT & SLIDE DOORS

ASE 60
If plenty of light and an impressive appearance are important to you, this system is ideally suited for large opening widths with large-scale glass constructions. Thermally insulated aluminum lift-and-slide system ASE 60 with its perfect water tightness, excellent sound reduction and burglar resistance is second to none.
In addition, enjoy the benefits of a new soft-line style that lends a smooth and elegant appearance. You can also choose an appropriate fly screen as a sliding unit. This fits seamlessly into the overall appearance.
PROFILE
CONFIGURATION
STANDARD
CONFIGURATION
POCKET
CONFIGURATION
CORNER
LIMITATIONS

MINIMUM SIZES

MINIMUM SIZES @300Pa | 6.27 psf
MAXIMUM SIZES
MAXIMUM WEIGHT
PANEL LIMITATIONS
470 mm x 540 mm

3500 mm x 3500 mm

500 kg
PERFORMANCE TEST
AIR INFILTRATION @300Pa | 6.27 psf
WATER PENETRATION
THERMAL - DOUBLE GLASS
DOOR PERFORMANCE

A3 | 0.4 L/s/m2 | 0.08 cfm/ft2

B5 | 580 Pa | 12.11 psf

1.84-2.03 W/m2K | 0.32-0.36 Btu

HANDLES
Black Interior
Silver Interior
Stainless Steel Interior
Black Exterior
Silver Exterior
Stainless Steel Exterior

DETAILS

Elegant and unique, this aluminum door adds vertical drama to any entrance. A perfectly flat surface with discreetly concealed handle and elongated window.
ASE 60

GLAZING & FINISHING OPTIONS

Elegant and unique, this aluminum door adds vertical drama to any entrance.
GLAZING & FINISHING
