Bi-Folding Doors

ASS 80 FD.HI
The Schuco ASS 80 FD.HI folding door offers a wide range of design options in both in-swing and out-swing typologies. With a basic depth of 80mm (3 1/8"), it offers high thermal insulation and industry leading maximum sizes, while maintaining a stylish and functional design. An optional low-profile threshold allows for barrier-free access.
The ASS 80 FD.HI is smooth and easy to operate, making it the perfect solution for commercial projects and luxury homes.
PROFILE
CONFIGURATION
LIMITATIONS

MINIMUM SIZES

MINIMUM SIZES @300Pa | 6.27 psf
MAXIMUM SIZES
MAXIMUM WEIGHT
PANEL LIMITATIONS
500 mm x 500 mm

1200 mm x 3000 mm

100 kg
PERFORMANCE TEST
AIR INFILTRATION @300Pa | 6.27 psf
WATER PENETRATION
THERMAL - DOUBLE GLASS
THERMAL - TRIPLE GLASS
DOOR PERFORMANCE

A2 | 0.66 L/s/m2 | 0.13 cfm/ft2

220 Pa | 4.6 psf

1.65-1.82 W/m2K | 0.29-0.32 Btu

1.25-1.48 W/m2K | 0.22-0.26 Btu

HANDLES
Black
Silver
Stainless Steel

DETAILS

Elegant and unique, this aluminum door adds vertical drama to any entrance. A perfectly flat surface with discreetly concealed handle and elongated window.
ASS 80 FD.HI

GLAZING & FINISHING OPTIONS

Elegant and unique, this aluminum door adds vertical drama to any entrance.
GLAZING & FINISHING
